TECHNICAL SPECIFICATIONS
| Parameter | Specification Details |
|---|---|
| Product Type | Thin-Film NTC Thermistor Sensor (Wired) |
| Sensing Head Material | Polyimide (Kapton) Film / Flexible Strip |
| Probe Thickness | Typical < 0.6mm (Ultra-Thin) |
| Response Time | ≤1s (Rapid Surface Detection) |
| Operating Temp | -40°C ~ +120°C |
| Resistance (R25) | Customizable: 10KΩ, 50KΩ, 100KΩ (±1%) |
| Beta Value (B25/50) | 3435K / 3950K |
| Cable Type | Flat Ribbon Cable or Discrete Wires |
| Application | Battery Cells, Smart Wearables, Surface Sensing |
ULTRA-THIN PROFILE
Engineered for applications where space is critical. With a profile thickness of less than 0.6mm, this sensor can be seamlessly integrated between battery cells or inside compact smart devices without altering the mechanical structure.
FLEXIBLE SURFACE SENSING
The flexible Polyimide (Kapton) film head conforms perfectly to curved surfaces. This ensures maximum contact area with the heat source (like a battery pouch), delivering faster and more accurate temperature readings than rigid sensors.
RAPID THERMAL RESPONSE
Due to its extremely low thermal mass and large contact area, this thin-film sensor offers a response time of ≤1 second. It detects rapid temperature changes instantly, which is vital for thermal runaway protection in BMS.
ROBUST & INSULATED
Despite its thinness, the sensor provides excellent electrical insulation and mechanical durability. It resists vibration and moisture, ensuring long-term reliability in automotive and industrial battery packs.
